PF30a-24 Ceramic Bottom Bracket

PF30a-24 ceramic bottom bracket converts Cannondale PF30a 73mm width frame to accept Shimano 24mm cranks.

Cannondale's new PF30a standard is released in 2016. The PF30a is similar to the PF30 standard, but the frame BB shell is 5mm wider on the non-drive side to make the total width from 68mm to 73mm.

This conversion bottom bracket in an integrated unit to allow a Shimano/FSA 24mm crankset run on a Cannondale PF30a frame without any additional adapters or spacers.

With the Grade 3 Si3N4 ceramic balls (8 times rounder and 4 times smoother than the steel's), spinning on the hardened ABEC 7 races, AITA's ceramic bearings run much smoother than most of the bearings in the market and only consume 20% of the power compared with the steel bearing, plus the bearings will last 3-5 times longer.

Unique designed dust cover improves the durability of the bottom bracket compared with the traditional Shimano’s design.

2 year warranty.

Free shipping worldwide.

Specifications:
CNC aluminium external BB cups;
ABEC7 high chrome vacuum degassed bearing steel races with quenching and tempering hardening;
Grade 3 Si3N4 ceramic bearing balls;
Nylon bearing retainer;
Dual lips light contact rubber bearing seals;

Frame requirements:
Cannondale PF30a standard frame;
Shell inner diameter 46mm and width 73mm;
i.e.SuperSix EVO 2016, Slice 2015-current, SuperX 2017

Crankset compatibility:
Shimano and FSA 24mm spindle cranksets.

Weight:
121g
